Ford Explorer: Climate Control System - General Information / Removal and Installation - Driver Temperature Door Actuator

Ford Explorer 2020-2024 Service Manual / Electrical / Climate Control System / Climate Control System - General Information / Removal and Installation - Driver Temperature Door Actuator

Removal

  1. Remove the glove compartment.
    Refer to: Glove Compartment (501-12 Instrument Panel and Console, Removal and Installation).

  1. Remove the screws and the driver temperature door actuator.
    • Disconnect the electrical connector.

Installation

  1. To install, reverse the removal procedure.

    Removal and Installation - Driver Side Register Air Discharge Temperature Sensor

    Removal Remove the IPC. Refer to: Instrument Panel Cluster (IPC) (413-01 Instrumentation, Message Center and Warning Chimes, Removal and Installation)...

    Removal and Installation - Evaporator

    Removal NOTICE: Use extreme care when releasing the tabs on the climate control housing, or the tabs can be easily damaged. NOTE: Removal steps in this procedure may contain installation detai..
