Ford Explorer: Climate Control System - General Information / Removal and Installation - Driver Side Register Air Discharge Temperature Sensor
Removal
-
Remove the IPC.
Refer to: Instrument Panel Cluster (IPC) (413-01 Instrumentation, Message Center and Warning Chimes, Removal and Installation).
-
Disconnect the electrical connector and remove the driver side register air discharge temperature sensor.
Installation
-
To install, reverse the removal procedure.
