Ford Explorer: Rear Climate Control / Removal and Installation - Rear Blower Motor Speed Control

Ford Explorer 2020-2023 Service Manual / Electrical / Climate Control System / Rear Climate Control / Removal and Installation - Rear Blower Motor Speed Control

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the RH loadspace trim panel.
    Refer to: Loadspace Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

    • Disconnect the electrical connector.
    • Depress the retaining tabs and remove the rear blower motor speed control.

Installation

  1. To install, reverse the removal procedure.
