Removal


  1. Push the stop tabs inwards and fully lower the glove compartment.
    • Remove the glove compartment check strap.
  1. Remove the screws and lower the cabin air filter door.
  1. Remove the cabin air filter.

Installation

  1. To install, reverse the removal procedure.
