Ford Explorer: Climate Control System - General Information / Removal and Installation - Passenger Side Footwell Air Discharge Temperature Sensor

Ford Explorer 2020-2025 Service Manual / Electrical / Climate Control System / Climate Control System - General Information / Removal and Installation - Passenger Side Footwell Air Discharge Temperature Sensor

Removal

Remove the floor console.
Refer to: Floor Console (501-12 Instrument Panel and Console, Removal and Installation).

Position the carpet aside.

Disconnect the electrical connector and remove the passenger side footwell air discharge temperature sensor.

Installation

To install, reverse the removal procedure.
