Ford Explorer: Climate Control System - General Information / Removal and Installation - Passenger Side Register

Ford Explorer 2020-2022 Service Manual / Electrical / Climate Control System / Climate Control System - General Information / Removal and Installation - Passenger Side Register

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Release the clips and remove the trim panel.

  1. Remove the bolts, release the clips and remove the display.
    • Disconnect the electrical connector.
      Torque: 19 lb.in (2.1 Nm)
  1. Release the clips and remove the center register trim panel.
    Use the General Equipment: Interior Trim Remover
  1. Release the clips and remove the RH instrument panel finish panel.
  1. Remove he bolt and the passenger side register.
  1. Release the tabs and remove the passenger side register from the trim panel.

Installation

  1. To install, reverse the removal procedure.
