Ford Explorer: Climate Control System - General Information / Removal and Installation - Center Registers

Ford Explorer 2020-2024 Service Manual / Electrical / Climate Control System / Climate Control System - General Information / Removal and Installation - Center Registers

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Release the clips and remove the trim panel.

  1. Remove the bolts, release the clips and remove the display.
    • Disconnect the electrical connector.
      Torque: 19 lb.in (2.1 Nm)
  1. Release the clips and remove the center register trim panel.
    Use the General Equipment: Interior Trim Remover
  1. Release the tabs and remove the center registers from the trim panel.

Installation

  1. To install reverse the removal procedure.

    Removal and Installation - Cabin Heater Coolant Pump - 2.3L EcoBoost (201kW/273PS)

    Special Tool(s) / General Equipment Hose Clamp(s) Hose Clamp Remover/Installer Fluid Container Removal NOTE: Removal steps in this procedure may contain installation details...

    Removal and Installation - Climate Control Housing

    Special Tool(s) / General Equipment Interior Trim Remover Removal NOTE: Removal steps in this procedure may contain installation details...
