Dimensions

Kia Picanto dimension diagram with reference letters for overall length, width, height, front and rear track, and wheelbase

The Kia Picanto dimensions below correspond to the reference letters in the illustration. Overall dimensions and front track measurements vary with the market, suspension specification and tyre size shown, so select the entry that matches your vehicle.

Reference	Dimension and applicable specification			mm (in)
A	Overall length	Europe and Russia		3,605 (141.5)
A	Overall length	Markets other than Europe and Russia		3,595 (141.9)
B	Overall width			1,595 (62.8)
C	Overall height	Europe and Australia		1,485 (58.5)
C	Overall height	Markets other than Europe and Australia		1,495 (58.9)
D	Front track width	Europe and Australia Excluding European versions with high suspension	175/65R14	1,406 (55.4)
			185/55R15	1,394 (54.9)
			195/45R16	1,394 (54.9)
		Markets other than Europe and Australia Also applicable to European versions with high suspension	175/65R14	1,403 (55.2)
			185/55R15	1,391 (54.7)
			195/45R16	1,391 (54.7)
	Rear track width	175/65R14		1,414 (55.6)
		185/55R15		1,402 (55.1)
		195/45R16		1,402 (55.1)
E	Wheelbase			2,400 (94.5)

Engine

The following tables list engine displacement, bore and stroke, firing order and cylinder count for the engine versions covered here. Identify the engine fitted to your Kia Picanto before using these specifications, as engines with similar names can have different dimensions and cylinder arrangements.

Specification	(Petrol) 1.0 MPI	(Petrol) 1.2 MPI
Displacement, cc (cu. in)	998 (60.9)	1,248 (76.2)
Bore × stroke, mm (in)	71 × 84 (2.8 × 3.3)	71 × 78.8 (2.80 × 3.10)
Firing order	1-2-3	1-3-4-2
Number of cylinders	3	4, in-line

Specification	Smartstream G1.0	Smartstream G1.0 GDi
Displacement, cc (cu. in)	998 (60.9)
Bore × stroke, mm (in)	71 × 84 (2.8 × 3.3)
Firing order	1-2-3
Number of cylinders	3

Specification	Smartstream G1.2	(Petrol) 1.0 FFV
Displacement, cc (cu. in)	1,197 (73.0)	998 (60.9)
Bore × stroke, mm (in)	71 × 75.6 (2.8 × 3.0)	71 × 84 (2.8 × 3.3)
Firing order	1-3-4-2	1-2-3
Number of cylinders	4, in-line	3
