Ford Explorer: Maintenance / Under Hood Overview - 3.3L

Ford Explorer 2020-2026 Owners Manual / Maintenance / Under Hood Overview - 3.3L

A - Battery. See Changing the 12V Battery.

B - Engine oil filler cap. See Engine Oil Check.

C - Engine oil dipstick. See Engine Oil Dipstick.

D - Brake fluid reservoir. See Brake Fluid Check.

E - Engine compartment fuse box. See Fuses.

F - Engine coolant reservoir cap. See Engine Coolant Check.

G - Air filter assembly. See Changing the Engine Air Filter.

H - Inverter system controller coolant reservoir cap- HEV only.

I - Washer fluid reservoir. See Washer Fluid Check.
