Removal

  1. Remove the driver side knee airbag.
    Refer to: Driver Knee Airbag (501-20B Supplemental Restraint System, Removal and Installation).
  1. Disconnect the electrical connector and remove the driver side footwell air discharge temperature sensor.

Installation

  1. To install, reverse the removal procedure.
