Ford Explorer: Supplemental Climate Control / Removal and Installation - Cabin Heater Coolant Temperature Sensor

Ford Explorer 2020-2022 Service Manual / Electrical / Climate Control System / Supplemental Climate Control / Removal and Installation - Cabin Heater Coolant Temperature Sensor

Special Tool(s) / General Equipment

Hose Clamp(s)

Removal

NOTE: Removal steps in this procedure may contain installation details.


    1. Disconnect the electrical connector.
    1. Remove the locking clip and remove the cabin heater coolant temperature sensor.
      Use the General Equipment: Hose Clamp(s)

Installation

  1. To install, reverse the removal procedure.
  1. Fill and bleed the cooling system. Refer to the appropriate procedure in Group 303.
