Removal

  1. Remove the climate control housing.
    Refer to: Climate Control Housing (412-00 Climate Control System - General Information, Removal and Installation).

  1. Remove the screws and the air inlet door actuator.
    • Disconnect the electrical connector.

Installation

  1. To install, reverse the removal procedure.
