System Operation

System Diagram


Item Description
1 ABS module
2 Hydraulic pressure sensor
3 EBB assembly
4 Wheel speed sensors
5 GWM
6 RCM
7 PSCM
8 BCM
9 ATCM ( AWD only)
10 PCM
11 IPC
12 IPMA
13 HVAC module
14 SCCM
15 GSM
16 PAM
17 SODR
18 SODL
19 Brake fluid level switch
20 Hydraulic pump motor
21 Hydraulic valve solenoids
22 Actuator position sensor
23 Traction control switch
24 Auto hold switch
25 TRM
26 AWD module
27 CCM
28 IPMB

Network Message Chart

  Module Network Input Messages - ABS Module


Broadcast Message Originating Module Message Purpose
Accelerator pedal position   PCM This message is sent to the GWM and then to the ABS module. This message provides the ABS module with the current accelerator pedal position and notifies the ABS module if the data is valid or invalid. The ABS module uses accelerator pedal position information for correct operation of the traction control, ESC, RSC and hill start assist systems.
Adaptive cruise control deceleration   CCM This message is sent to the IPMA and then to the ABS module. This message contains the amount of deceleration currently required by the adaptive cruise control system to maintain the distance gap set by the driver.
Adaptive cruise control braking precharge   CCM This message is sent to the IPMA and then to the ABS module. This message is sent by the CCM to request precharging of the brake system in preparation for adaptive cruise control deceleration from the ABS module.
Adaptive cruise control braking request   CCM This message is sent to the IPMA and then to the ABS module. This message is sent by the CCM to request adaptive cruise control braking from the ABS module.
Ambient air temperature   PCM This message is sent to the GWM and then to the ABS module. The ABS module uses this information for calculations in determining the operational status of the various stability control systems and features.
Auto hold switch status HVAC Module This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the auto hold switch status; pressed, not pressed or faulty.
Battery voltage   BCM This message is sent to the GWM and then to the ABS module. This message provides the ABS module with the current 12-volt battery and charging system voltage.
Brake pedal applied   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of driver brake pedal application.
Collision mitigation deceleration   CCM This message is sent to the IPMA and then to the ABS module. This message contains the amount of deceleration currently required by the CCM to assist in collision avoidance.
Collision mitigation braking precharge   CCM This message is sent to the IPMA and then to the ABS module. This message is sent by the CCM to request precharging of the brake system in preparation for collision mitigation deceleration from the ABS module.
Collision mitigation braking request   CCM This message is sent to the IPMA and then to the ABS module. This message is sent by the CCM to request collision mitigation braking from the ABS module.
Cruise control override request   PCM This message is sent to the GWM and then to the ABS module. This message is sent by the CCM to request adaptive cruise control braking from the ABS module.
Cruise control mode   PCM This message is sent to the GWM and then to the ABS module. This message provides the ABS module with the current cruise control mode; not active, keeping speed, accelerating, decelerating, resuming high, resuming low, tap up waiting, or tap down waiting. The ABS module modifies anti-lock braking and stability control operations based on the messages received.
Cruise control status   PCM This message is sent to the GWM and then to the ABS module. This message provides the ABS module with the current cruise control status; off, denied, standby denied, standby, active que assist, active undefined 1, or undefined 2. The ABS module modifies anti-lock braking and stability control operations based on the messages received.
Driven wheel torque output   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current torque output available at the driven wheels. This information is used for the traction control, hill start assist, ESC and RSC feature operation.
Driver seatbelt buckle status   RCM Informs the ABS module of the current driver seat belt buckle status, buckled or unbuckled. The ABS module uses this information for the electric parking brake drive away release feature.
Engine status   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current engine status; engine off, engine on, engine auto stopped, or not used.
Engine RPM   PCM This message is sent to the GWM and then to the ABS module. Used to inform the ABS module of the current engine RPM. The ABS module uses this information for EPB drive away release feature, traction control, ESC, RSC and hill start assist operations.
Hill descent control request   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module the driver has requested the hill descent control system to be activated or deactivated.
Hill descent control switch   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module the driver has requested the hill descent control system to be activated or deactivated.
Hill start assist request   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module a hill start assist operation is currently active.
Ignition key type   BCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current ignition key type; standard or MyKey. The ABS modifies operating parameters if a restricted MyKey is used.
Ignition status   BCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current ignition status; off, accessory, run, start, unknown or invalid.
Neutral tow command   GSM Informs the ABS module of the current transmission neutral tow status; normal mode, car wash mode, neutral tow mode or not used.
Odometer master value   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current odometer mileage.
Parking brake request   GSM A request from the GSM to apply the parking brake.
Powertrain status   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current powertrain status; off_torque not available, on_torque not available, start in progress_torque not available or on_torque available.
Rear differential lock status AWD Module Informs the ABS module of the current rear differential locked status; no fault, unspecified fault, differential failed open and differential failed closed. The ABS module requests rear differential unlocking during traction control, ESC and RSC operations.
Rear differential locking torque AWD Module Informs the ABS module of the current amount of torque being applied to the rear differential. The ABS module requests rear differential unlocking during traction control, ESC and RSC operations.
RCM serial number   RCM This message is sent to the GWM and then to the ABS module. The ABS module stores the RCM serial number and verifies the serial number when the vehicle is started or the ignition is set to ON or ACC. Over time, the ABS module learns the offset of the stability sensors inside the RCM. When a new RCM serial number is found and the ABS Calibration routine is carried out using a diagnostic scan tool, the ABS module resets the offset values learned for the yaw rate sensor, lateral accelerometer and roll rate sensor.
Reverse gear status   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current reverse gear status; inactive not confirmed, inactive confirmed, active not confirmed, or active confirmed. This information is used for hill start assist, ESC and RSC operation. Hill start assist operates in forward and reverse gears. ESC and RSC do not operate when the transmission is in REVERSE.
Selectable drive mode brake request   IPC Informs the ABS module of the current brake drive mode request; Normal, Sport, Tow/Haul, Eco, Slippery, Deep Snow/Sand, or Trail.
Selectable drive mode chassis request   VDM Informs the ABS module of the current chassis drive mode request; Not Available, Available, Temporarily Not Available or Faulty.
Selectable drive mode powertrain request   PCM Informs the ABS module of the current powertrain drive mode request; Not Available, Available, Temporarily Not Available or Faulty.
Selectable drive mode steering status   PSCM Informs the ABS module of the current PSCM selectable drive mode switch status; Not Available, Available, Temporarily Not Available or Faulty.
Selectable drive mode suspension status   VDM Informs the ABS module of the current VDM selectable drive mode switch status; Not Available, Available, Temporarily Not Available or Faulty.
Selectable drive mode switch status   ATCM Informs the ABS module of the current selectable drive mode switch status; not pressed, switch state 1, switch state 2, or faulty.
Stability-traction control mode request   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module the driver has requested a change to enable or disable the traction control, ESC or RSC.
Stability-traction control MyKey request   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module the MyKey feature has been configured to Always On.
Steering wheel angle information   PSCM The ABS module uses steering angle sensor information for ESC and RSC operation. This message provides the ABS module with the current steering wheel angle in degrees as well as the steering wheel angle count (number or revolutions).
Trailer brake lamp connection   TRM Informs the ABS module a trailer with brake lamps is connected to the vehicle.
Trailer sway control configuration   IPC This message is sent to the GWM and then to the ABS module. This message informs the ABS module the driver has requested the trailer sway control system to be activated or deactivated.
Transfer case lock status AWD Module Informs the ABS module of the current transfer case locked status; OK, opened by command, inactive, fault, warning, disabled, fully locked by command, torque limited by command, under external torque control and undefined. The ABS module requests transfer case unlocking during traction control, ESC and RSC operations.
Transfer case locking torque AWD Module Informs the ABS module of the current amount of torque being applied to the transfer case. The ABS module requests the transfer case to unlock during traction control, ESC and RSC operation.
Transfer case range AWD Module Informs the ABS module of the current transfer case range; low, neutral or high. The ABS module modifies the thresholds for traction control, ESC and RSC intervention based on the current transfer case range.
Transmission gear lever position   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current driver selected gear lever position.
Transmission gear   PCM This message is sent to the GWM and then to the ABS module. This message informs the ABS module of the current transmission gear.
Vehicle configuration data   BCM This message is sent to the GWM and then to the ABS module. This message provides the ABS module with the current optional and configured items such as tire size, axle ratio, manual or automatic transaxle, keyless entry and VIN.
Vehicle lateral acceleration data   RCM This message provides the ABS module with the current vehicle lateral acceleration data and notifies the ABS module if the data is valid or invalid. The ABS module uses the lateral acceleration data for traction control, ESC and RSC operation.
Vehicle longitudinal acceleration data   RCM This message provides the ABS module with the current vehicle longitudinal acceleration data and notifies the ABS module if the data is valid or invalid. The ABS module uses the longitudinal acceleration data for ESC and RSC operation.
Vehicle roll rate data   RCM This message provides the ABS module with the current vehicle roll rate data and notifies the ABS module if the data is valid or invalid. The ABS module uses the yaw rate data for RSC operation.
Vehicle yaw rate data   RCM This message provides the ABS module with the current vehicle yaw rate data and notifies the ABS module if the data is valid or invalid. The ABS module uses the yaw rate data for ESC and RSC operation.

Anti-Lock Brake System (ABS) Function

The ABS module continuously monitors brake pedal input, lateral vehicle motion and the rotational speed of each wheel. The PCM sends the brake pedal switch information to the GWM over the HS-CAN1, the GWM sends the information to the ABS module over the HS-CAN2. The RCM sends lateral acceleration sensor information directly to the ABS module over the HS-CAN2. Wheel speed information is retrieved by the ABS module using 4 active wheel speed sensors. When the ABS module detects an impending wheel lock during a braking event, the ABS module modulates brake pressure to the appropriate brake calipers by opening and closing the appropriate solenoid valves inside the HCU while the hydraulic pump motor is activated. Once the affected wheel returns to the desired speed, the ABS module deactivates the hydraulic pump motor and returns the solenoid valves to their normal position.

The ABS module has 2 self-test options, one uses a diagnostic scan tool and the other is carried out when the ABS module is initialized (ignition ON). During either self-test the ABS module carries out a preliminary electrical check of the system sensors and activates the hydraulic pump motor for approximately one-half second. During this time, a buzzing or humming noise may be heard and a vibration may be felt in the brake pedal; this is a normal condition. During the module initialized self-test, the pump motor check is carried out at approximately 10 km/h (6 mph). Any malfunction detected in the system causes the ABS module to set a DTC, disable the ABS function and send a message over the HS-CAN2 to the GWM. The GWM then sends the message to the IPC over the HS-CAN3 to illuminate the ABS warning indicator. Diagnostic Trouble Codes (DTCs) which disable the ABS do not disable the base hydraulic power-assist braking system.

Auto Hold

The auto hold feature is activated and deactivated through the use of the auto hold switch located on the instrument panel. For the system to activate, the vehicle must not be moving, the driver safety belt must be buckled and the driver door must be closed.

The ABS module receives the driver safety belt buckle status from the RCM, driver door status from the BCM, while brake system pressure and the wheel speed are received from ABS sensors. This information allows the ABS module to determine if the vehicle is stopped. Once the previous conditions have been met the auto hold feature can be activated. When the switch is pressed, the HVAC module receives a ground signal from the auto hold switch and sends an auto hold message to the GWM over the HS-CAN3. The GWM relays the message to the ABS module over the HS-CAN2.

The ABS module then sends a message to the instrument cluster through the GWM indicating the auto hold feature has been activated and the instrument cluster illuminates the auto hold indicator.

The auto hold indicator illuminates when the IPC receives a message from the ABS module through the GWM.

Once the auto hold feature is activated and the driver presses the brake pedal, the ABS module closes the isolation valves in the HCU to maintain the current brake system pressure at the wheel ends. The ABS module maintains the pressure until the driver presses the accelerator pedal, shifts the transmission into PARK or after a specific time limit has been reached. The ABS module engages the parking brake after 2-10 minutes, depending on the grade of incline the vehicle is currently stopped on, the steeper the grade, the shorter the time.

Electronic Brake Force Distribution (EBD)

On initial application of the brake pedal, full pressure is applied to the rear brakes. The ABS module uses wheel speed sensor inputs to evaluate rear wheel slip. Once the rear wheel slip exceeds a predetermined threshold, the ABS module commands the HCU to close the appropriate isolation valves to hold the rear brake pressure constant while allowing the front brake pressure to build. This creates a balanced braking condition between the front and rear wheels. If the rear wheel slip continues and exceeds a second predetermined threshold, the ABS module commands the HCU to open the dump valves to decrease the rear brake pressure and allow the rear wheels to recover. A slight bump sensation may be felt in the brake pedal when EBD is active. If the ABS is disabled due to Diagnostic Trouble Codes (DTCs) being present in the ABS module, EBD continues to function unless the Diagnostic Trouble Codes (DTCs) are for wheel speed sensors or the HCU solenoid valves. When EBD is disabled, the ABS warning indicator, the red brake warning indicator and traction control indicator illuminate.

Emergency Brake Assist (EBA)

The EBA feature helps drivers in a severe braking event, such as an emergency, by applying the maximum possible braking force.

If the brake pedal is pressed very suddenly, the ABS module increases the hydraulic pressure to all of the brakes until the threshold for ABS intervention is reached. This generates the maximum braking power for the available traction. The ABS module monitors inputs from the brake pedal switch and from the pressure sensor within the HCU to check for sudden actuation of the brakes. With the brake pedal pressed, the ABS module triggers emergency braking if the rate of increase of hydraulic pressure exceeds the predetermined limit.

If the brake pedal is pressed so hard the ABS becomes active on the front wheels, the ABS module increases the pressure to the rear wheels up to the ABS intervention threshold.

EBA operation continues until the driver releases the brake pedal sufficiently for the hydraulic pressure in the HCU to drop below a specific threshold value. This threshold is saved in the ABS module.

Hill Descent Control

When the hill descent control switch is pressed, the ATCM sends a hill descent braking assist message to the ABS module over the HS-CAN2. Once the vehicle speed is 3-32 km/h (2-20 mph) and the transmission is in REVERSE or any forward gear, the ABS module uses the hydraulic pump motor and the HCU solenoid valves to maintain the vehicle speed set by the driver. If the vehicle speed is increased or decreased outside of the operational window, the system remains active but descent speed cannot be set or maintained.

The Hill Descent Control feature requires a cool down period after sustained use. The ABS module continually monitors the descent speed, angle of descent, pump motor run time and solenoid valve use. Once the ABS module determines a cool down period is needed, the module sends a message to the GWM over the HS-CAN2. The GWM relays the message to the IPC over the HS-CAN3 to display HILL DESCENT CONTROL OFF SYSTEM COOLING in the message center.

Hill descent control has 3 modes of operation:

  • At 3-32 km/h (2-20 mph) when the hill descent control switch is pressed and conditions are correct for hill descent activation, the hill descent control system is enabled and active. The hill descent indicator flashes indicating the feature is active and the message center indicates hill descent control is active.
  • At 32-64 km/h (20-40 mph) when the hill descent control switch is pressed and conditions are correct for hill descent activation, the hill descent control system is enabled, but not active. The hill descent control indicator illuminates solidly and a message is displayed in the message center indicating the reason hill descent is not active.
  • At more than 64 km/h (40 mph) when the hill descent control switch is pressed, the hill descent control system is not enabled and the hill descent control indicator does not illuminate. The hill descent control feature can only be activated when vehicle speed is below 64 km/h (40 mph).

Hill Start Assist

When the vehicle is stopped on an incline greater than approximately a 5% grade, the ABS module holds the brake pressure for approximately 1.5 seconds while the driver transitions from the brake pedal to the accelerator pedal. This is accomplished by monitoring several HS-CAN messages and several sensors to determine if the vehicle is stopped and not parked, and if the vehicle is on an appropriate incline.

  • The brake pedal message from the PCM and the wheel speed sensor inputs allow the ABS module to determine the vehicle has come to a complete stop.
  • The transmission selector lever message sent by the GSM allow the ABS module to determine the vehicle is not parked.
  • The stability sensor messages sent by the RCM allow the ABS module to determine if the vehicle is on an appropriate incline.

Once the above conditions have been met, hill start assist automatically engages. Before the driver releases the brake pedal, the ABS module commands the HCU to close the isolation valves which maintains the current brake system pressure, preventing the vehicle from rolling down the incline. Once the driver presses the accelerator pedal and the engine RPM increases, the ABS module gradually releases the brake pressure to make sure the vehicle is neither rolling back nor driving off until there is sufficient driving torque to accelerate the vehicle forward (or backward if reversing up the incline).

Hydraulic Fade Compensation and Brake Fluid Support

Hydraulic fade compensation and brake fluid support provides a function to counteract faded brakes by supplying additional wheel brake pressure, if the maximum achievable vehicle deceleration is not reached, while the driver applies (very) high pedal force (driver brake request remains longer than a predetermined time). Brake fluid support provides a software function to increase fluid flow to the wheel end brakes in the event the brakes have faded to the extent the primary or secondary master cylinder circuits can no longer supply fluid to the brake system.

Supplemental Braking Assist

In addition to preventing wheel lock up during braking events, the ABS module also provides supplemental hydraulic brake assist through the use of the hydraulic pump motor and the HCU. This is done in the event of a severe braking event, to maintain the distance gap set by the adaptive cruise control system or to assist with collision avoidance.

The ABS module continually monitors CAN messages and sensor inputs. When the messages or sensors indicate a severe braking event is about to occur or is occurring, the ABS module activates the hydraulic pump motor in the HCU to assist with vehicle braking.

On vehicles equipped with adaptive cruise control, the CCM monitors the area forward of the vehicle.

When an object enters this area and closes the distance gap set by the driver, the CCM sends a deceleration request to the IPMA over a LIN. The IPMA then sends the message to the ABS module over the HS-CAN2.

When the deceleration request message is received, the ABS module activates the hydraulic pump motor and solenoid valves in the HCU to slow the vehicle down to maintain the distance gap set by the driver. Once the distance gap set by the driver is achieved, the CCM stops sending the deceleration request message and the ABS module deactivates the hydraulic pump motor and solenoid valves in the HCU.

If the CCM determines the amount of braking provided by the ABS module is insufficient, the CCM sends a forward collision avoidance braking request message and warns the driver, both audibly and visually, through the use of the HUD. After receiving the braking request message, the ABS module waits for brake pedal input and, once received, applies maximum braking assist using the hydraulic pump motor and the HCU.

For additional information on the adaptive cruise control system,
Refer to: Cruise Control - System Operation and Component Description (419-03B Cruise Control - Vehicles With: Adaptive Cruise Control With Lane Centering, Description and Operation).

For additional information on the collision avoidance system,
Refer to: Collision Warning and Collision Avoidance System - System Operation and Component Description (419-03C Collision Warning and Collision Avoidance System, Description and Operation).

AdvanceTrac

The AdvanceTrac system is comprised of the ESC and traction control features.

Electronic Stability Control (ESC)

The ABS module continuously monitors the vehicle motion relative to the intended course. This is done by using sensors to compare the steering wheel input and the yaw rate sensor input with the actual vehicle motion.

The PSCM sends the steering wheel angle information to the ABS module over the HS-CAN2. The RCM sends yaw rate sensor and lateral accelerometer information to the ABS module also over the HS-CAN2. If the ABS module determines from the inputs the vehicle is unable to travel in the intended direction, it modulates brake pressure to the appropriate brake calipers by opening and closing the appropriate solenoid valves inside the HCU while the hydraulic pump motor is activated. At the same time, the ABS module calculates how much engine torque reduction is required to help stabilize the vehicle and sends this torque reduction message to the GWM over the HS-CAN2 which relays the message to the PCM over the HS-CAN1. The ABS module also sends a vehicle stability event message to the GWM over the HS-CAN2 which relays this message to the IPC over the HS-CAN3. When the PCM receives the torque reduction message, it adjusts engine timing and decreases fuel injector pulses to reduce the engine torque to the requested level. When the IPC receives the vehicle stability event message, it flashes the stability-traction control indicator (sliding car icon).

Once the vehicle instability has been corrected, the ABS module returns the solenoid valves in the HCU to their normal position, deactivates the hydraulic pump motor and stops sending the traction event and torque reduction messages. The PCM returns engine timing and fuel injectors to normal operation and the IPC extinguishes the stability-traction control indicator (sliding car icon).

The ESC can be disabled by the driver using the stability-traction control switch. This is independent of ABS which cannot be disabled by the driver. The stability-traction control switch is hardwired to the IPC, when the driver presses the stability-traction control switch, the switch sends a ground signal to the IPC. The IPC responds by illuminating the stability-traction control disabled indicator (sliding car OFF icon) and by sending a message to the GWM over the HS-CAN3. The GWM relays this message to the ABS module over the HS-CAN2. The ABS module takes no further action in regards to stability-traction until the driver presses the switch again in the same ignition cycle, the ignition is cycled from OFF to ON or vehicle speed exceeds 56 km/h (35 mph). For additional information on disabling the traction control feature, refer to Disabling AdvanceTrac.

ESC does not operate with the transmission in REVERSE or with the transfer case in 4WD low. The ABS module disables ESC if there are any wheel speed sensor, stability sensor or steering angle sensor Diagnostic Trouble Codes (DTCs) present in the ABS module. If there is a communication error between the ABS module and the PSCM or the ABS module and the RCM, ESC also is disabled. When ESC is disabled, the ABS module sends a message to the GWM over the HS-CAN2. The GWM relays this message to the IPC over the HS-CAN3 to illuminate the stability-traction control indicator (sliding car icon).

Traction Control

The ABS module continuously monitors and compares the rotational speed of the drive wheels in relation to the non-driven wheels. When the drive wheels begin to spin faster than the non-driven wheels, the ABS module modulates brake pressure to the appropriate brake calipers by opening and closing the appropriate solenoid valves inside the HCU while the hydraulic pump motor is activated. At the same time, the ABS module calculates how much engine torque reduction is required to eliminate the wheel slip and sends this torque reduction message to the GWM over the HS-CAN2 which relays the message to the PCM over the HS-CAN1. The ABS module also sends a traction event message to the GWM over the HS-CAN2 which relays this message to the IPC over the HS-CAN3. When the PCM receives the torque reduction message, it adjusts engine timing and decreases fuel injector pulses to reduce the engine torque to the requested level. When the IPC receives the traction event message, it flashes the stability-traction control indicator (sliding car icon).

Once the driven wheel speed returns to the desired speed, the ABS module returns the solenoid valves in the HCU to their normal position, deactivates the hydraulic pump motor and stops sending the traction event and torque reduction messages. The PCM returns engine timing and fuel injectors to normal operation and the IPC extinguishes the stability-traction control indicator (sliding car icon). Once vehicle speed exceeds 100 km/h (62 mph), traction control is accomplished only through the PCM torque control.

The traction control system can be disabled by the driver using the traction control switch (if equipped) or through the message center. This is independent of ABS which cannot be disabled by the driver. The traction control switch is hardwired to the IPC, when the driver presses the traction control switch, the switch sends a ground signal to the IPC. The IPC responds by illuminating the stability-traction control disabled indicator (sliding car OFF icon) and by sending a message to the GWM over the HS-CAN3. The GWM relays this message to the ABS module over the HS-CAN2. The ABS module takes no further action in regards to traction control until the driver presses the switch again in the same ignition cycle or until the ignition is cycled from OFF to ON. For additional information on disabling the traction control feature, refer to Disabling AdvanceTrac.

The ABS module disables traction control if there are any wheel speed sensor or solenoid valve Diagnostic Trouble Codes (DTCs) present in the ABS module. Traction control is also disabled if there is a communication error between the ABS module and the PCM. When traction control is disabled, the ABS module sends a message to the GWM over the HS-CAN2. The GWM relays this message to the IPC over the HS-CAN3 to illuminate the stability-traction control indicator (sliding car icon).

Curve Control

The ABS module continuously monitors the vehicle motion relative to the intended course. This is done by using sensors to compare the steering wheel input, the yaw rate sensor input, the lateral acceleration sensor input and the longitudinal acceleration sensor input with the actual vehicle motion.

The PSCM sends the steering wheel angle information to the ABS module over the HS-CAN2. The RCM sends yaw rate sensor and lateral accelerometer information to the ABS module also over the HS-CAN2. If the ABS module determines from the inputs the vehicle is experiencing over-steer or under-steer, the ABS module modulates brake pressure to the appropriate brake calipers by opening and closing the appropriate solenoid valves inside the HCU while the hydraulic pump motor is activated. At the same time, the ABS module calculates how much engine torque reduction is required to help stabilize the vehicle and sends this torque reduction message to the GWM over the HS-CAN2 which relays the message to the PCM over the HS-CAN1. The ABS module also sends a curve control event message to the GWM over the HS-CAN2 which relays this message to the IPC over the HS-CAN3. When the PCM receives the torque reduction message, it adjusts engine timing and decreases fuel injector pulses to reduce the engine torque to the requested level. When the IPC receives the vehicle stability event message, it flashes the stability-traction control indicator (sliding car icon).

The curve control function does not operate with the transmission in REVERSE. The ABS module disables the curve control function if there are any wheel speed sensor, stability sensor or steering angle sensor Diagnostics Trouble Codes (DTCs) present in the ABS module. The curve control function is also disabled if there is a communication error between the ABS module and the PSCM, or the ABS module and the RCM. When the curve control function is disabled, the ABS module sends a message to the GWM over the HS-CAN2. The GWM relays this message to the IPC over the HS-CAN3 to illuminate the stability-traction control indicator (sliding car icon).

Roll Stability Control (RSC)

The ABS module continuously monitors the vehicle motion relative to the intended course. This is done by using sensors to compare the steering wheel input, yaw rate sensor input, lateral accelerometer input and roll sensor input with the actual vehicle motion.

The PSCM sends the steering wheel angle information to the ABS module over the HS-CAN2. The RCM sends yaw rate sensor, lateral accelerometer and roll rate sensor information to the ABS module also over the HS-CAN2. If the ABS module determines from the inputs the vehicle is becoming unstable, the ABS module modulates brake pressure to the appropriate brake calipers by opening and closing the appropriate solenoid valves inside the HCU while the hydraulic pump motor is activated. At the same time, the ABS module calculates how much engine torque reduction is required to help stabilize the vehicle and sends this torque reduction message to the GWM over the HS-CAN2 which relays the message to the PCM over the HS-CAN1. The ABS module also sends a vehicle stability event message to the GWM over the HS-CAN2 which relays this message to the IPC over the HS-CAN3. When the PCM receives the torque reduction message, it adjusts engine timing and decreases fuel injector pulses to reduce the engine torque to the requested level. When the IPC receives the vehicle stability event message, it flashes the stability-traction control indicator (sliding car icon).

Once the vehicle instability has been corrected, the ABS module returns the solenoid valves in the HCU to their normal position, deactivates the hydraulic pump motor and stops sending the traction event and torque reduction messages. The PCM returns engine timing and fuel injectors to normal operation and the IPC extinguishes the stability-traction control indicator (sliding car icon).

RSC does not operate with the transmission in REVERSE or with the transfer case in 4WD low. The ABS module disables RSC if there are any wheel speed sensor, stability sensor or steering angle sensor Diagnostic Trouble Codes (DTCs) present in the ABS module. If there is a communication error between the ABS module and the SASM or the ABS module and the RCM, RSC also is disabled. When RSC is disabled, the ABS module sends a message to the GWM over the HS-CAN2. The GWM relays this message to the IPC over the HS-CAN3 to illuminate the stability-traction control indicator (sliding car icon).

Trailer Sway Control

Trailer sway is the undesirable yaw force a trailer can apply to the towing vehicle. Trailer sway control is a unique function of the stability control system that uses steering wheel angle information and yaw rate information to determine if a trailer sway event is taking place.

The PSCM sends the steering wheel angle information to the ABS module over the HS-CAN2. The RCM sends yaw rate sensor and lateral accelerometer information to the ABS module also over the HS-CAN2. If the ABS module determines from the inputs a trailer sway event is taking place, the ABS module modulates brake pressure to the appropriate brake calipers by opening and closing the appropriate solenoid valves inside the HCU while the hydraulic pump motor is activated. At the same time, the ABS module calculates how much engine torque reduction is required to eliminate the trailer sway and sends this torque reduction message to the GWM over the HS-CAN2 which relays the message to the PCM over the HS-CAN1. The ABS module also sends a trailer sway event message to the GWM over the HS-CAN2 which relays this message to the IPC over the HS-CAN3. When the PCM receives the torque reduction message, it adjusts engine timing and decreases fuel injector pulses to reduce the engine torque to the requested level. When the IPC receives the vehicle stability event message, it flashes the stability-traction control indicator (sliding car icon) and displays TRAILER SWAY REDUCE SPEED in the message center.

Once the trailer sway has been corrected, the ABS module returns the solenoid valves in the HCU to their normal position, deactivates the hydraulic pump motor and stops sending the traction event and torque reduction messages. The PCM returns engine timing and fuel injectors to normal operation and the IPC extinguishes the stability-traction control indicator (sliding car icon) and stops displaying the trailer sway message in the message center. Trailer sway control only activates when vehicle speed is greater than 65 km/h (40 mph). Any malfunction disabling RSC also disables trailer sway control.

The driver can enable and disable the trailer sway control feature using the message center and steering wheel controls. For additional information, refer to the Owner's Literature.

Selectable Drive Modes

The selectable drive mode system optimizes driveability and comfort as well as maximizing traction while operating on different types of terrain. The ATCM controls the drive mode selection. When a drive mode is selected, the ATCM sends the drive mode message to the ABS module over the HS-CAN2. When the ABS module receives the message, it alters the intervention thresholds for ESC, RSC and traction control based on the selected mode. The ABS module also sends the drive mode message out to several other modules. The following modules receive the message and respond by altering their operation as follows:

  • PSCM: adjusts steering effort and feel based on the selected mode.
  • PCM: adjusts throttle response and gear changes to enhance powertrain response based on the selected mode.
  • AWD module: automatically engages and disengages specific 4WD modes and raises or lowers torque output based on the selected mode.

The following drive modes are available:

  • Deep Snow/Sand: For soft dry sand or deep snow.
  • Eco: For efficient and responsible driving. Eco helps deliver maximum fuel efficiency and increases driving range.
  • Normal: Used for normal, everyday on-road driving and towing. The Tow-Haul function can only be used in Normal mode.
  • Slippery: For firm surfaces covered with loose or slippery material such as packed snow, ice, water, grass or a thin layer of gravel or sand.
  • Sport: Used for more spirited on-road driving; increases throttle response, provides a sportier steering feel, along with quicker shifting. The transmission also holds gears longer, helping the vehicle accelerate faster when shifting gears.
  • Tow/Haul: For improved transmission operation when towing a trailer or a heavy load. Tow Haul moves upshifts to higher engine speeds to reduce the frequency of transmission shifting. This mode also provides engine braking in all forward gears.
  • Trail: For muddy, rutted, soft or uneven terrain.

Drive mode changes are not available when the ignition is off. If a mode is unavailable, the system defaults to Normal mode.

MyKey® Interaction

Through the MyKey® feature, traction control can be configured to be always on or to allow the driver to select the traction control function on or off. When the traction control function is configured to be always on and a MyKey® restricted key is in use, the IPC ignores any requests made by the driver to disable the traction control function and does not send any traction control disable messages to the GWM. Refer to the Owner's Literature for additional information on the various MyKey® settings.

Stability-Traction Control Indicator (Sliding Car Icon)

One or both of the stability/traction control indicators may illuminate as a result of momentary sensor disturbances due to environmental or driving conditions (including severe vehicle maneuvers or extreme off road usage). Once illuminated, the indicator remains on until the environmental or driving condition is no longer present and the ignition is cycled from ON to OFF and then back to ON again. If there are no other customer concerns, symptoms, indicators or Diagnostic Trouble Codes (DTCs), the stability/traction control indicator may have been illuminated due to these environmental or driving conditions.


Refer to: Instrument Panel Cluster (IPC) - System Operation and Component Description (413-01 Instrumentation, Message Center and Warning Chimes, Description and Operation).

Stability-Traction Control Disabled Indicator (Sliding Car OFF Icon)


Refer to: Instrument Panel Cluster (IPC) - System Operation and Component Description (413-01 Instrumentation, Message Center and Warning Chimes, Description and Operation).

Electronic Parking Brake Features

The ABS module is the controlling ECU for the electronic parking brake system and controls all parking brake features such as automatic drive away release. For additional information on the electronic parking brake system,
Refer to: Parking Brake - System Operation and Component Description (206-05 Parking Brake and Actuation, Description and Operation).

Component Description

Auto Hold Switch

The auto hold switch is a momentary contact, push button switch and is part of the HVAC module.

Brake Fluid Level Switch

The brake fluid level switch is mounted on the mini-reservoir attached to the EBB assembly and is hardwired to the ABS module. The ABS module provides a reference voltage to the brake fluid level switch and the switch is grounded through the ABS module along a separate ground circuit.

Drive Mode Switch

The drive mode switch is a multi-position, rotating switch and is part of the ATCM.

Electric Brake Booster (EBB) Assembly

The EBB is serviced as a single assembly and should NOT be disassembled. The EBB assembly contains the ABS module, solenoid valves, pressure sensor and hydraulic pump motor; the EBB also takes the place of the brake master cylinder and the vacuum booster.

The ABS module is serviced as an assembly with the EBB. The ABS module is the ECU for the ABS and stability control systems. The module monitors all sensor inputs and all CAN messages relating to ABS and stability control, then directly controls the solenoid valves and the hydraulic pump motor in the EBB. When a new EBB assembly is installed, the ABS module must be programmed with the current vehicle configuration information. For additional information on module programming,
Refer to: Module Configuration - System Operation and Component Description (418-01 Module Configuration, Description and Operation).

When an ABS or stability control fault has been corrected or a new component has been installed, the ABS module must be calibrated using the ABS Calibration routine found on the diagnostic scan tool. ABS Calibration is required for the stability control sensors to learn the zero-position of the vehicle which means the vehicle must be on a level surface and not moving.

Hill Descent Control Switch

The hill descent control switch is a single-pole, momentary-contact switch and is part of the ATCM.

Stability Control Sensors

The stability control sensors for the traction control and ESC functions consist of the yaw rate sensor, lateral accelerometer, longitudinal accelerometer and roll rate sensor. The sensors are housed in the RCM which sends sensor information to the ABS module over the HS-CAN2. If any of the sensors are defective, a new RCM must be installed.

  • The yaw rate sensor measures the yaw angle which is the difference between the direction the vehicle is pointing when cornering and the direction the vehicle is actually moving.
  • The longitudinal accelerometer measures the acceleration and deceleration of the vehicle as it moves forward and backward.
  • The lateral accelerometer measures the force created when a vehicle corners that tends to push a vehicle sideways.
  • The roll rate sensor measures the rate of rotation of the vehicle along the centerline of the vehicle from front to back.

Lateral acceleration has 2 forms. The first is the centrifugal acceleration that is generated when the vehicle travels around in a circle. The second is the acceleration due to gravity. On level ground there is no lateral acceleration due to gravity. However, if the vehicle is parked sideways on a bank or an incline, the sensor measures some lateral acceleration due to gravity, even though the vehicle is not moving.

Steering Wheel Angle Sensor

Information from the wheel speed sensors, PSCM and RCM are used by the ABS module to determine steering wheel angle when the vehicle is driven after initial start up. The ABS module uses the information received to calculate the steering center and saves the information in memory. Then, using the information provided from the PSCM along with the saved center data, the ABS module determines the steering angle. The ABS module must re-learn the steering center whenever power is lost, for example during service when the battery is disconnected. To re-learn the steering center, the vehicle must be driven over 20 km/h (12 mph) for at least 1 minute on a fairly straight road.

Traction Control Switch

The traction control switch is a single-pole, momentary-contact switch and is part of a switch pack in the center console.

Wheel Speed Sensor

All 4 wheel speed sensors are active (magneto resistive) sensors that operate on the Hall-effect principle to generate a square wave signal proportional to the rotational speed of the wheel. Because these are active sensors, receiving voltage from the ABS module and sending a varying voltage back to the ABS module, they are able to detect much lower rotational speeds than passive (magnetic inductive) sensors. Each wheel speed sensor is connected to the ABS module by 2 circuits which are used for both sensor power and sensor signal return.

Wheel Speed Sensor Encoder Rings

The wheel speed sensor encoder rings are magnetized, toothed rings used to create a Hall-effect switch when combined with the wheel speed sensor. The encoder rings are part of the front and rear wheel hub and bearing assemblies and are serviced with the assemblies.

    Description and Operation - Anti-Lock Brake System (ABS) and Stability Control - Overview

    Overview The ABS and stability control systems are comprised of the following subsystems to assist the driver in maintaining control of the vehicle: ABS Curve control Drive away..

    Removal and Installation - Electric Brake Booster (EBB)

    Removal NOTE: Removal steps in this procedure may contain installation details. NOTE: The EBB and the ABS module are serviced as an assembly and should not be separated...

    Other information:

    Ford Explorer 2020-2021 Service Manual: Removal and Installation - Front Parking Aid Sensor


    Removal Remove the front bumper cover. Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation). Remove the front parking aid sensor. Disconnect the electrical connector. Release the tabs. Remove the sensor...

    Ford Explorer 2020-2021 Service Manual: Removal and Installation - Front Seat Cushion Blower Motor


    Removal Raise the front seat to its highest point of travel. Remove the front seat cushion blower motor. Disconnect the electrical connector. Rotate the blower motor 45 degrees clockwise. Installation To install, reverse the removal procedure...

    Categories

    Fastening the Seatbelts

    The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts.

    read more


    Copyright © 2021 www.foexplorer.com
