Ford Explorer: Maintenance / Under Hood Overview - 2.3L EcoBoost™

Ford Explorer 2020-2023 Owners Manual / Maintenance / Under Hood Overview - 2.3L EcoBoost™

A - Battery. See Changing the 12V Battery.

B - Engine oil filler cap. See Engine Oil Check.

C - Engine oil dipstick. See Engine Oil Dipstick.

D - Brake fluid reservoir. See Brake Fluid Check.

E - Engine compartment fusebox. See Changing a Fuse.

F - Engine coolant reservoir. See Engine Coolant Check.

G - Air filter assembly. See Changing the Engine Air Filter.

H - Windshield washer fluid reservoir. See Washer Fluid Check.

    Opening and Closing the Hood

    Opening the Hood Open the left-hand front door. Fully pull the hood release lever and let it completely retract. Note: This action releases the hood latch...

    Under Hood Overview - 3.0L

    A - Battery. See Changing the 12V Battery. B - Engine oil filler cap. See Engine Oil Check. C - Engine oil dipstick. See Engine Oil Dipstick. D - Brake fluid reservoir...
