Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the air cleaner outlet pipe.
    Refer to: Air Cleaner Outlet Pipe (303-12A Intake Air Distribution and Filtering - 2.3L EcoBoost (201kW/273PS), Removal and Installation).
  1. Disconnect the electrical connector and remove the A/C pressure transducer.

Installation

  1. To install, reverse the removal procedure.
