Kia Picanto: If you have a flat tyre (with spare tyre): (if equipped) / Jack label. Example. Declaration of Conformity for Jack

Jack label. Example

Example

Figure 1. Type A

Figure 2. Type B

The jack label in your Kia Picanto may look different from the examples shown. For detailed specifications and instructions, refer to the label attached to the jack.

1. Model name

2. Maximum permitted load

3. Apply the parking brake before using the jack.

4. Switch off the engine before using the jack.

5. Never get underneath a vehicle supported by a jack.

6. Use the designated jacking points beneath the frame.

7. When raising the vehicle, keep the jack base plate vertical beneath the lifting point.

8. For a manual transmission, select reverse gear. For an automatic transmission, move the shift lever to P (Park).

9. Use the jack only on firm, level ground.

10. Jack manufacturer

11. Production date

12. Representative company and address

Declaration of Conformity for Jack

CE

UKCA
